MASSPHOTON Upper Room UV Air Disinfection / Upper-room UVGI System MP-UVC-15WR

Name: MASSPHOTON Upper Room UV Air Disinfection / Upper-room UVGI System MP-UVC-15WR
Brand: MASSPHOTON
Rating: 5.0 (76 reviews)


Availability:

Quantity:



Inquire Add to Basket

MASSPHOTON UVC Upper Air Disinfection is an intelligent, sensor-based building-grade Upper Room UV Air Disinfection system powered by advanced UVC LED technology. It enables continuous Upper-room GUV operation in occupied spaces, drawing exhaled aerosols into the upper UV-C zone via natural or mechanical airflow for rapid pathogen inactivation—eliminating up to 99.99% of airborne threats more efficiently than HVAC-only systems.

Applicable Environments: Suitable for dry/damp environments with wall/ceiling mounting options. Seamlessly adapts to hospitals, schools, offices, restaurants, retail—virtually maintenance-free as a proven UVC Upper Air Disinfection solution.

Model:
MP-UVC-15WR
Brand:
MASSPHOTON

Product Description

Typical Applications

Technical Information

Product Overview

The MASSPHOTON UVC Upper Air Disinfection system is an intelligent, sensor-based, building-grade Upper-room GUV and UVGI Air Disinfection solution powered by advanced UVC LED technology. Designed for continuous, intelligent, and safe disinfection in occupied spaces, the system harnesses the germicidal efficiency of high-intensity UVC LEDs together with natural convection or mechanical ventilation. Airborne pathogens and exhaled aerosols are continuously drawn into the upper UVC treatment zone for rapid cyclical inactivation.
Compared with conventional HVAC-dependent solutions, the MASSPHOTON UVC Upper Air Disinfection system eliminates up to 99.99% of airborne pathogens, delivering superior air quality and enhanced protection. Its modular, sensor-driven design allows seamless integration into environments such as hospitals, classrooms, offices, restaurants, retail, and public facilities—offering continuous, contact-free safety without interrupting daily activity.

Key Features

UVC LED Technology Advantage

Utilizes independently developed high-efficiency UVC LED light sources to replace traditional mercury lamps, delivering instant on/off, mercury-free and eco-friendly operation, no ozone generation, extended lifespan, and dramatically reduced maintenance. Only periodic cleaning and routine inspections are required — enabling uninterrupted long-term continuous operation with no business downtime or personnel evacuation.

Real-Time Upper-room UV Air Disinfection

Creates a persistent upper-room UVGI zone, continuously disinfecting the air above occupied levels for real-time protection, with inactivation rates of up to 99.9% (or higher) for targeted pathogens. Particularly suitable for high-traffic areas, it delivers ongoing air disinfection while ensuring occupant safety.

Smart Presence-Sensing Control

Integrates PIR human presence sensors for automatic occupancy detection: activates high-efficiency upper-air disinfection mode when occupied, and switches to energy-saving standby or enhanced disinfection mode when unoccupied. Intelligent on-demand operation delivers up to 30% energy savings.

Contactless Zero-Interference Design

The upper-room GUV irradiation zone is maintained well above head height, producing no odor, no chemical residues, and requiring no personnel evacuation. It enables true 24/7 continuous operation in occupied spaces, delivering a genuine “install and forget” automated protection experience.

Broad Area Coverag

Modular design supports both wall-mount and ceiling-mount installations; its slim profile seamlessly blends into various indoor environments and suits diverse applications. It can integrate with HVAC systems to create an enhanced air circulation disinfection chain, delivering large-scale air disinfection for comprehensive whole-room UVGI air protection coverage.

Certified Scientific Validation

We conduct in-house research and support third-party testing, providing quantifiable disinfection efficacy and performance data to ensure the product's effectiveness is genuine and reliable, with both safety and performance rigorously verified by science.

Typical Applications

MASSPHOTON UVC Upper Air Disinfection excels in public/commercial spaces demanding superior air hygiene via Upper-room UVGI System.

Retail：

Discreet Upper-room GUV continuously purifies store air, rebuilding consumer confidence and enhancing shopping experiences.

Hotels：

Continuous UVGI Air Disinfection across lobbies/rooms ensures pathogen-free air, delivering peace-of-mind guest stays.

Restaurants：

Upper-air UVGI zones in kitchens/dining block contamination, maintaining safe dining for customers and staff.

Fitness Centers：

High-density UVC Upper Air Disinfection with ventilation protects members/trainers in active spaces.

Schools：

Multi-zone Upper Room UV Air Disinfection across classrooms/corridors enables safe, uninterrupted learning.

Assisted Living：

Constant Upper-room UVGI System safeguards vulnerable residents in lounges/dining/activity areas.

Commercial Offices：

Upper-room GUV ensures clean circulation in open offices/meeting rooms, reducing transmission risks.

Healthcare & Laboratories：

Upper-room GUV prevents cross-contamination in ERs/isolation zones for medical-grade hygiene.

Transit & Waiting Areas：

Ideal for airports, metro stations, terminals, and waiting lounges—creating continuous disinfection barriers for high-traffic air environments.

Technical Information

No.	Specifications
1	Model	MP-UVC-15WR
2	UVC Peak Wavelength	275 ± 5 nm
3	Radiant Flux (UVC Output)	≥ 4.2 W (at an ambient temperature of 25°C)
4	Irradiance(1m Distance)	Approx. 41 μW/cm²
5	Rated Input Voltage	DC 36V (to be used with a dedicated power adapter)
6	Rated Power	15W
7	Operating Current	1.7A
8	Lamp Body Material	Aluminum alloy heat dissipation base + quartz glass
9	Protection Class	IP20 (dust-proof, not waterproof)
10	Installation Method	Equipped with standard mounting clips
11	Heat Dissipation Method	Active fan cooling with side air outlet (Do not block the air outlets on both sides)
12	Ambient Temperature	-20°C ~ +40°C
13	Storage Temperature	-30°C ~ +60°C
14	Relative Humidity	< 85% (non-condensing)
